Electec Building Wiring Systems - ELECTEC Building Wiring SystemsElectec Building Wiring Systems

Innovative, prefabricated wiring systems
for efficient building and infrastructure projects

Delivering Value

Modular wiring systems from ELECTEC deliver value at every stage of your building’s life cycle. Our systems are industry proven with hundreds of installations across North America.

Environmentally-Responsible

ELECTEC represents the environmentally-responsible approach to building wiring and cabling. Eco-friendly products, constructed with low-smoke zero-halogen materials designed for cost-effective reusability and relocation.

Features and Benifits

Compliance and Certification

UL Listed – Meets UL 183 Manufactured Wiring Systems standards.
CSA Certified – Compliant with CSA 22.2 No. 203‑1.
Ballast Disconnect Means per NEC 410.73(g) & CEC 30‑308(4)
Plenum‑Rated per NEC 300‑22(c) & CEC 12‑010(3)

High‑Performance Cable and Connectors

LTRALX® MC/AC90 Cable (300 lb tension; 12 AWG, 600 V, 20 A)
SJOW Cord Option for flexible cord applications.
Robust Terminal Design – Withstands 470 A for 4 seconds.
Full Load Make/Break – Rated to interrupt current under full load safely.

Safety and Reliability

Low‑Smoke Zero‑Halogen (LSZH) Materials – RoHS‑compliant, V‑0 flame rating; dielectric withstand up to 3000 Vac.
Fully Encapsulated, High‑Impact Polymer Housings – Superior strength, halogen‑free for environmental safety.
Self‑Latching, Shrouded Connectors – Prevents accidental disconnection and enhances arc‑flash protection.
Uniquely Keyed and Color‑Coded – Error‑proof mating: only like‑colored connectors plug together.

Installation and Life‑Cycle Value

Reusable & Relocatable – Prefab modules bolt into place; reroute or reuse as needs change.
Proven Track Record – Hundreds of installations across North America, reducing labor and commissioning time.
Economical – Cuts on‑site wiring labor by up to 30% and minimizes downtime.
